| Name | Inverter Transformer |
|---|---|
| Power | 375W |
| Operation Temperature | -40℃ To +65℃ |
| Isolation | 3000Vdc |
| Frequency | 350KHz |
| Name | Inverter Transformer |
|---|---|
| Power | 25kW |
| Operation Temperature | -40℃ To +105℃ |
| Isolation | 4000Vdc |
| Frequency | 50KHz~350KHz |
| Name | Switch Mode Power Transformer |
|---|---|
| Power | 250W |
| Type | EE Type, ER Type, EI Type, PQ Type |
| Thickness | 10.0mm |
| Operation Temperature | -40℃ To +125℃ |
| Type | Power Transformer |
|---|---|
| Operating Frequency | 100KHz |
| Core | Mn-Zn Ferrite |
| Thickness | 12.5mm |
| Operation Temperature | -40℃ To +125℃ |
| Type | Planar Transformer |
|---|---|
| Frequency | 200KHz To 500KHz |
| Core | Mn-Zn Ferrite |
| Thickness | 8.3mm |
| Operation Temperature | -40℃ To +125℃ |
| Type | High Frequency Planar Transformer |
|---|---|
| Power | 15W |
| Pad Size | 14.6*16.58mm |
| Thickness | 5.8mm |
| Operation Temperature | -40℃ To +125℃ |
| Frequency | 50KHz To 3000KHz |
|---|---|
| Power | 180W |
| Pad Size | 29.5 Mm×26.7 Mm |
| Thickness | 11mm |
| Operation Temperature | -40℃ To +125℃ |
| Frequency | 200KHz To 700KHz |
|---|---|
| Power | 75W |
| Pad Size | 20.3*18.5mm |
| Thickness | 6.6mm |
| Operation Temperature | -40℃ To +125℃ |
| Frequency | High Frequency |
|---|---|
| Power | 10W To 120KW |
| Installation | SMD LEAD |
| Hi-Pot | 1500Vdc |
| Operation Temperature | -40℃ To +125℃ |
| Frequency | High Frequency |
|---|---|
| Power | 10W To 120KW |
| Installation | SMD LEAD |
| Hi-Pot | 1500Vdc |
| Operation Temperature | -40℃ To +125℃ |
