| Usage | High Frequency |
|---|---|
| Application | Power, Electronic, Instrument, Lighting, Rectifier, Audio, Charger, Lamp, Communication Equipment |
| Insulation | UL Insulation System For Class B (130), F (155), H (180) |
| Product Name | EE1309 Ferrite Core Transformer |
| Certification | ISO9001-2000, UL, ISO9001, CCC, CE |
| Name | Signal Transformers |
|---|---|
| Turns Ratio | 1：10 |
| Core Material | EE5.0 Ferrite Core |
| Operating Temperature | -25℃to+125℃ |
| Storage Temperature | -25℃to+85℃ |
| Usage | Balance Current |
|---|---|
| Structure Of Magnetizer | Mn-Zn Ferrite Core |
| Product Name | Drive Transformer |
| Power Range | 500-900mW |
| Certification | RoHS/SGS/ISO9001 |
| Core Material | RM14 Ferrite Core |
|---|---|
| Operating Frequency | 10~500KHZ |
| Operating Temperature | -40℃to+125℃ |
| Storage Temperature | -25℃to+85℃ |
| Features Low Loss, Large Transmission Power, Low Temperature Rise, Stable Performance Material Ferri | Horizontal,Vertical,SMD |
| Usage | Single-phase Transformer, Rectifier Transformer, Combined Transformer, Power Transformer |
|---|---|
| Structure Of Magnetizer | Mn-Zn Ferrite Core |
| Product Name | Flyback Transformer |
| Model Number | EP5/EP7/EP10/EP13 Etc. |
| Certification | RoHS/SGS/ISO9001 |
| Usage | High Frequency |
|---|---|
| Application | Power, Electronic, Instrument, Lighting, Rectifier, Audio, Industrial |
| Core Type | POT Core |
| Product Name | Mn-Zn Ferrite Core Transformer |
| Certification | UL, ISO9001, IATF16949, ISO14001 |
| Usage | High Frequency |
|---|---|
| Application | Power, Electronic, Instrument, Lighting, Rectifier, Audio, Industrial |
| Voltage Ratio | 1:18V |
| Product Name | Mn-Zn Ferrite Core Transformer |
| Certification | UL, ISO9001, IATF16949, ISO14001 |
| Usage | High Frequency |
|---|---|
| Application | Power, Electronic, Instrument, Lighting, Rectifier, Audio, Charger, Lamp, Communication Equipment |
| Insulation | UL Insulation System For Class B (130), F (155), H (180) |
| Product Name | EFD Ferrite Core Transformer |
| Certification | ISO9001-2000, UL, ISO9001, CCC, CE |
| Usage | Single-phase Transformer, Rectifier Transformer, Power Transformer |
|---|---|
| Working Power | 0.5W-1000W |
| Product Name | EER Typ Ferrite Core Transformer |
| Certification | ISO9001 |
| Application | Power, Electronic, Instrument, Lighting, Rectifier, Audio |
| Usage | High Frequency |
|---|---|
| Core | E65*2PRS |
| Core Material | Ferrite Core |
| Appication | Welding Machine |
| Certification | RoHS/SGS/ISO9001 |
