10kHz Common Mode Choke Coil Magnetic Core Flat Wire Inductor

Common Mode Choke Coil , Flat Wire Inductor , Inductance Customized

          Flat Wire Inductor High current, small profile, high efficiency with High frequency skin effect of flat wire, unit current density can reach 1.5-2 times of round copper wire, and the volume will be 0.5-1.0 times smaller under the same condition,Lower temperature coefficient, only around once layer winding, perfect efficiency of heat sink , the temperature raise is much lower than the toroidal inductor

FEATURES:

• Rated voltage (V): 85 to 250V AC, 50/60Hz
• Turns ratio: n1: n2=1:1
• Insulation resistance: 100mΩ min at 500DC
• Replacement for: EE16,EE19,EE25,EF16,EF20,EF25,UU10.5, UU16,toroidal common mode inductors
• Interturn capacitance is smaller than toroidal core, high insulation strength and high reliability
• The closed magnetic core design
• Single phase winding, thereby dramatically reduce stray capacitance
• EMI suppression is excellent
• Fully automatic winding, neat line arrangement, no overlapping, high production efficiency, low labor

APPLICATION:

• Switching power supply, Adapter and UPS
• Computer products
• LED power supply
• LCD TV & Monitor Displays Power Boards
• Consumer Electric Products & Battery Charger, Printers

Notes: Customized is available
